2022 Kawasaki Teryx KRX 1000 Trail Edition
QR Code Link to This Post
Ask for: Sales
☎ (209) 580-4062
487 S Hwy 59 MERCED, CA 95340-4439
Enter this link to see more images plus all other inventory we have available:
https://lyv.cc/DHY43
2022 Kawasaki Teryx KRX 1000 Trail Edition
Price: Call for Pricing
Basic Information:
- Year: 2022
- Make: Kawasaki
- Model: Teryx KRX
- Trim: 1000 Trail Edition
- Stock Number: U502885
- VIN: JKARFCB16NB502885
- Condition: Used
- Type: Sport Utility
- Frame: Steel
- Front Adjustable Fork Pre-Load
- Front Suspension Brand Name: Fox Podium
- Front Travel (in): 18.6
- Front Travel (mm): 472.4
- Number Rear Shock Absorbers: 2
- Rear Adjustable Shock / Spring Pre-Load
- Rear Stabilizer Bar
- Rear Suspension Brand Name: Fox Podium
- Rear Travel (in): 21.1
- Rear Travel (mm): 535.9
- Steering Control: Steering Wheel
- Steering Type: Power
- Suspension - Front: Independent Double Wishbone
- Suspension - Rear: Independent
- Clock
- Digital Instrumentation
- Hour Meter
- Seat Material: Vinyl
- Seat Type: Bucket
- Transmission Type: Continuously Variable (CVT)
- Engine Braking System
- Differential Lock
- Differential Lock Location: Front
- Driveline Type: Selectable 4X2 / 4X4
- Number Of Driveline Modes: 2
- Rear Unlocking Differential
- Hi / Low Range
- Primary Drive (Front Wheel): Shaft
- Primary Drive (Rear Wheel): Shaft
- Reverse
- Limited Slip Differential
- Limited Slip Differential Location: Front
- Primary Drive (Engine / Transmission): Belt
- Bore (in): 3.62
- Bore (mm): 92
- Carburetion Type: Fuel Injected
- Compression Ratio: 11.5
- Cylinders: 2
- Displacement (ci): 60.9
- Engine Cooling: Liquid
- Engine Size (cc): 999
- Engine Stroke: 4-Stroke
- Fuel Capacity (gal): 10.6
- Fuel Injector
- Fuel Injector Size (mm): 50
- Fuel Requirements: Regular
- Snorkel Air Intake
- Starter Type: Electric
- Stroke (in): 2.96
- Stroke (mm): 75.1
- Torque (Ft Lbs): 76.7
- Torque (Nm): 104
- Torque RPM: 7000
- Valve Configuration: DOHC
- Valves: 4
- Valves Per Cylinder: 2
- Cab Cage
- Cab Canopy
- Cab Canopy Material: Hard
- Cab Doors
- Cab Doors Material: Hard
- Cab Rollbar
- Cargo Bed Integral Tie-Down Hooks
- Power Outlet
- Brush Guard
- Nerf Bars
- Brakes - Front: Dual Hydraulic Disc
- Brakes - Rear: Dual Hydraulic Disc
- Front Brake Diameter (in): 10.2
- Front Brake Diameter (mm): 258
- Rear Brake Diameter (in): 10.2
- Rear Brake Diameter (mm): 258
- Roller Fairlead
- Seat Belts
- Headlight(s)
- Bash Plate (Front)
- Bed Capacity (kgs.): 159.2
- Bed Capacity (lbs.): 351
- Body Material: Plastic
- Cargo Bed Bed Height (in): 9.1
- Cargo Bed Bed Height (mm): 231.1
- Cargo Bed Bed Length (in): 14.6
- Cargo Bed Bed Length (mm): 370.8
- Cargo Bed Bed Width (in): 33.1
- Cargo Bed Bed Width (mm): 840.7
- Cargo Bed Material: Polyethylene
- Cargo Bed Tilt
- Front Tire Diameter (in): 31
- Front Tire Width: 10
- Tread Width (in): 59.3
- Tread Width (mm): 1505
- Full Length Skid Plate
- Ground Clearance (in): 13.6
- Ground Clearance (mm): 345.4
- Height (Inches): 76
- Height (mm): 1945.6
- Length (ft): 50
- Length (mm): 3385.8
- Payload Capacity (kgs): 354.3
- Rear Hitch
- Rear Tire Diameter (in): 31
- Rear Tire Width: 10
- Rear Tread Width (in): 59.4
- Rear Tread Width (mm): 1510
- Turning Radius (ft): 20.3
- Wet Weight (kg): 916.2
- Wet Weight (lbs): 2019.8
- Wheelbase (in): 98.8
- Wheelbase (mm): 2509.5
- Wheels Composition: Aluminum
- Width (Inches): 68
- Width (mm): 1729.7
- Winch
- Winch Brand Name: Warn
- Winch Weight (kgs): 2041.2
- Winch Weight (lbs): 4500
Description:
2022 Kawasaki Teryx KRX 1000 Trail Edition – Only 902 Miles!
California Custom Trailers & Powersports – Merced, CA
? 902 Miles | Excellent Condition
Tough, reliable, and built to conquer any trail — this 2022 Kawasaki Teryx KRX 1000 Trail Edition is the perfect combination of comfort, power, and durability. With just 902 miles, this machine is lightly used and ready to ride!
Specs:
Model: 2022 Kawasaki Teryx KRX 1000 Trail Edition
Miles: 902
Condition: Excellent / Light Use
Location: California Custom Trailers & Powersports – Merced, CA
? Trail Edition Features:
999cc Parallel-Twin Engine – Smooth, reliable power
FOX 2.5 Podium LSC Shocks – Built for aggressive terrain
Maxxis Carnivore Tires on 15” Beadlock Wheels
KQR Sport Roof for shade and protection
Full Skid Plates for underbody protection
Front & Rear Bumpers – Trail-ready protection
LED Lighting – Bright and efficient
Durable CVT & Crawl-Ready Gear Ratios
Everything you need for trail, rock, or desert — no need to add a thing.
Asking Price: $15,500 OBO
? Plus applicable taxes & registration fees
This is a clean, low-mileage KRX that’s trail-ready and priced to sell. Don’t miss out!
Contact or Visit Us Today:
California Custom Trailers & Powersports
487 S Highway 59, Merced, CA 95341
(209) 580-4062 Engine Type: 4-stroke, DOHC, 8-valve parallel-twin, liquid cooled
Displacement: 999cc
Bore and Stroke: 92.0 x 75.1 mm
Cooling: Liquid
Compression Ratio: 11.5:1
Fuel System: DFI with two 50mm throttle bodies
Ignition: TCBI with electronic advance
Front Suspension: Double wishbone, FOX 2.5 PODIUM LSC shocks with piggyback reservoir, fully adjustable preload, and 24-position adjustable compression damping
Front Brakes: Dual hydraulic discs with two-piston calipers
Front Tire: MAXXIS Carnivore 31 x 10.00R15 8PR
Rear Suspension: 4-link trailing-arm rear suspension, FOX 2.5 PODIUM LSC shocks with piggyback reservoir, fully adjustable preload, and 24-position adjustable compression damping
Rear Brakes: Dual hydraulic discs with single-piston calipers
Rear Tire: MAXXIS Carnivore 31 x 10.00R15 8PR
Dry Weight: Curb Weight: 2019.8 lb.s (2022.0 CA)
Wheelbase: 98.8 in.
Front Travel: 18.6 in..
Rear Travel: 21.1 in..
Ground Clearance: 14.2 in. (max), 13.6 in. (std)
Fuel Capacity: 10.6 gal.
Box Capacity: 351 lb.s
Transmission: Automatic CVT with centrifugal clutch (H,L,N,R)
Drive System: Selectable 2WD/4WD with locking front differential, shaft
Colors: Fragment Camo Gray
